Product Summary
The ADG4288P is a monolithic CMOS analog multiplexer comprised eight single channels and four differen-tial channels respectively. On-chip address and control latches facilitate microprocessor interfacing. The ADG4288P switches one of eight inputs to a common output as determined by the 3-bit binary address lines A0, A1 and A2. An EN input on both devices is used to enable or disable the device. When disabled, all channels are switched OFF. All the control inputs, address and enable inputs are TTL compatible over the full specified operating temperature range. The applications of the ADG4288P include Automatic Test Equipment, Data Acquisition Systems, Communication Systems, Avionics and Military Systems, Microprocessor Controlled Analog Systems, Medical Instrumentation.
Parametrics
ADG4288P absolute maximum ratings: (1)VDDto VSS: +44 V; (2)VDDto GND: -0.3 V to +25 V; (3)VSSto GND: +0.3 V to -25 V; (4)Analog, Digital Inputs: VSS -2 V to VDD +2 V or 30 mA, Whichever Occurs First; (5)Continuous Current, S or D: 30 mA; (6)Peak Current, S or D: 100 mA, Operating Temperature Range; Industrial (B Version): -40℃ to +85℃; (7)Extended (T Version): -55℃ to +125℃; (8)Storage Temperature Range: -65℃ to +150℃; (9)Junction Temperature: +150℃; (10)Cerdip Package, Power Dissipation: 900 mW, θJA, Thermal Impedance: 73℃/W; Lead Temperature, Soldering (10 sec): +300℃; (11)Plastic Package, Power Dissipation: 470 mW; θJA, Thermal Impedance: 115℃/W; Lead Temperature, Soldering (10 sec): +260℃; (12)SOIC Package, Power Dissipation: 600 mW; θJA, Thermal Impedance: 77℃/W; Lead Temperature, Soldering; Vapor Phase (60 sec): +215℃; (13)PLCC Package, Power Dissipation: 800 mW; θJA, Thermal Impedance: 90℃/W; Lead Temperature, Soldering, Vapor Phase (60 sec): +215℃; Infrared (15 sec): +220℃.
Features
ADG4288P features: (1)44 V Supply Maximum Ratings; (2)VSSto VDDAnalog Signal Range; (3)Low On Resistance (60 Vtyp); (4)Low Power Consumption (1.6 mW max); (5)Low Charge Injection (<4 pC typ); (6)Fast Switching; (7)Break-Before-Make Switching Action; (8)Plug-In Replacement for DG428/DG429.
