Product Summary

The BU7238KVT is a Low Voltage CMOS. The BU7238KVT integrates one op-amp or two independent op-amps and phase compensation capacitor on a single chip. The features of the BU7238KVT are low operating supplyVoltage that is +1.8V to +5.5V(single supply) and low supply current, extremely low input bias current.

Parametrics

BU7238KVT absolute maximum ratings: (1)Supply Voltage, VDD-VSS: +7V; (2)Differential Input Voltage, Vid: VDD-VSS V; (3)Input Common-mode voltage range, Vicm: (VSS-0.3) to VDD +0.3V; (4)Operating Temperature, Topr: -40 to +85℃; (5)Storage Temperature, Tstg: -55 to +125℃; (6)Maximum junction Temperature, Tjmax: +125℃.

Features

BU7238KVT features: (1)Low operating supply voltage (+1.8V to +5.5V); (2)+1.8 V to +5.5V(single supply); ±0.9V to ±2.75V(split supply); (3)Input and Output full swing; (4)Push-pull output type ; (5)High speed operation; (6)Low supply current; (7)Internal ESD protection Human body model (HBM) ±4000V(Typ.); (8)Wide temperature range, -40℃ to +85℃.

Diagrams

BU7238KVT block diagram
